|Specifications
| Working Voltage | DC 48V | Overall Machine Dimensions (L x W x H) (mm) | 890 x 676 x 1070 |
Battry Life | • Dust Mopping: 10 h • Floor Washing: 5 h | Battery Capacity | Lithium Battery 30 AH |
| Cleaning Efficiency | 2160 m²/h | Charging | Standard Charging: 2h Fast Charging 1 h |
| Clean Water Tank Capacity | 46 L | Dirty Water Tank Capacity | 46 L |
| Cleaning Width | 500 mm (Dual Brushes) | Water Suction Width | 700 mm |
| Cleaning Speed | 1.2 m/s | Operating Noise | 60 dB(A) |
| Water Suction Motor Power | 310 W | Brush Contact Pressure | 33 kg |
| Disc Brush Motor Power | 300 W (150 W x 2) | Drive Motor Power | 600 W (300 W x 2) |
| Disc Brush Speed | 275 rpm/min | Climbing Gradien | 0-8° |
| Water Volume Adjustment | Intelligent Electronic Valve | Obstacle-Crossing Ability | 1 cm |
| Machine Weight | 145 kg | Squeegee Lift | Electric |
| Disc Brush Lift | Electric | Bumper Anti-Collision Device | Available |
| Motor Overload Protection | Available | Minimum Passage Width | 900 mm |
| Emergency Stop Button | Available | Minimum Turning Radius | 1300 mm |
| Edge Cleaning Distance | 100-200 mm |
|Key Highlights
All-in-One Multi-Purpose Cleaning: Integrates scrubbing, vacuuming, and dry mopping. Effortlessly handles oil stains, water marks, dust, and small debris like cigarette butts and paper scraps.
Fully Autonomous 24/7 Operation: Compatible with an auto-service station for automatic drainage, refilling, and self-charging. Achieves true "hands-free" operation with zero downtime.
Smart Elevator Integration (IoT Control): Utilizes advanced communication protocols to interact with elevator systems. The robot can independently request floors, enter/exit elevators, and return to the charging station across multiple levels.
Digitalized Cleaning & Cloud Management:
Remote Control: Manage equipment via Mobile/PC APP with remote diagnostics for instant troubleshooting.
Data-Driven Insights: The backend cloud platform generates automated cleaning reports, enabling enterprises to optimize efficiency through digital management.
Aerospace-Grade Durability & Fast Charging: Built with modular architecture and industrial/aerospace-grade components. Equipped with a 48V/30AH Li-ion battery, supporting 1-hour fast charging for high-frequency tasks.
|Functional Features
1. 6-Layer Advanced Safety System:
Powered by 3D+2D LiDAR, RGB-D cameras, and ultrasonic sensors. Precise identification of overhanging, low-profile, and dynamic obstacles (e.g., forklifts, racks). Includes anti-drop, emergency stop, and safety touch edges.
2. Modular "Quick-Change" Design:
Core electrical and mechanical parts can be replaced within 10 minutes.
Tool-less Maintenance: Brushes and squeegees can be swapped on-site in as little as 10 seconds.
3. Intelligent Path Planning:
Supports "One-Key Start" for pre-defined tasks, including path optimization, customized working durations, and cycle counts.
4. NFC Instant Activation:
Features NFC "One-Touch" start for simplified operation, reducing training time for on-site staff.
|Application Scenarios
Factory | Workshop
Airport | Station
Warehouse | Logistics
Hospital | School
Office Building | Hotel
Shopping Mall | Campus
