|Specifications
| Sweeping Width | 1400 mm | Working Speed | 1-10km/h |
| Side Brush Motor Power | 100 W x 2 | Gradeability | ≤ 35° |
| Working Voltage | 48 V | Working Noise | 60 dB(A) |
| Total Operating Power | 3900 W | Dust Collection Motor Power | 420 W |
| Water Tank Capacity | 60 L | Main Brush Motor Power | 700 W |
| Garbage Capacity | 170 L | Main Brush Size | 700mm |
| Battery Life | 3-4 h | Side Brush Size | 500mm |
| Travel Motor Power | 2500 W | Working Efficiency | 10000 m²/h |
| Water Spraying Duration | 60 min | Machine Weight | 600 kg |
| Battery Capacity | 100 AH | Machine Dimensions (L x W x H) (mm) | 1900*1450*1900 |
| Dust Collection Filter Area | 6 m² | Package Dimensions (L x W x H) (mm) | 2000*1300*2000 |
| Filter Material | Drum-Type Dust Separator Filter |
|
|
|Key Highlights
Advanced Control System: Equipped with a U.S. KELLY Controller, ensuring the highest level of system stability and operational reliability.
High-Strength Automotive Steel Structure: The industry's first to adopt an automotive-grade high-steel frame. It is 150kg lighter than traditional sheet metal structures, significantly reducing energy consumption and extending battery life.
Superior Powertrain & Climbing Ability: Powered by a 2500W Rare Earth Permanent Magnet AC Drive Motor with a high-torque reduction transaxle. Designed with a 3x overload capacity, it delivers performance comparable to a car, with a remarkable gradeability of up to 35°.
High-Efficiency Dust Suppression System: Features a 500W Rare Earth Permanent Magnet Suction Motor that maintains stable suction even at low battery levels. Equipped with an original imported Toray (Japan) polyester drum filter (6 ㎡ filtration area) and a built-in electric vibrator for quick, tool-free cleaning. Independent suction control supports operation in rainy conditions.
Patented Suspension System: Features a patented balanced hydraulic damping system that automatically adjusts balance during inclines, reducing vibration and increasing operator comfort while lowering the failure rate.
|Functional Features
1. Premium Coating & Corrosion Resistance:
The body undergoes a triple-layer painting process (interior and exterior) for superior oxidation and corrosion resistance.
2. Automotive-Grade Safety Glass:
The integrated canopy features tempered glass (same grade as High-Speed Rail), which is shatter-proof to ensure maximum safety for the operator.
3. Rugged Component Design:
Side Brushes: Reinforced steel structure, impact-resistant and rust-proof.
Water Tank: Made with thick, rotomolded material for extreme durability.
Hardware: Entirely assembled with stainless steel screws to prevent rust.
4. Smart Maintenance:
Includes a built-in automatic dust vibration device and an air gun interface for high-efficiency cleaning of the filters.
5. Flexible Battery Options:
Standard 4 x 100AH maintenance-free batteries provide 4-5 hours of runtime; Lithium battery options are also available for higher-intensity requirements.
