|Specifications
| Sweeping Width | 2000 mm | Working Speed | 7-10km/h |
| Side Brush Motor Power | 100 W * 4 | Gradeability | ≤ 35° |
| Working Voltage | 48 V | Working Noise | 60 dB(A) |
| Total Operating Power | 4280 W | Dust Collection Motor Power | 600 W |
| Water Tank Capacity | 60 L | Main Brush Motor Power | 700 W |
| Garbage Capacity | 190 L | Main Brush Size | 700mm |
| Battery Life | 4-6 h | Side Brush Size | 500mm |
| Travel Motor Power | 2500 W | Filter Material | Drum-Type Dust Separator Filter |
| Water Spraying Duration | 60 min | Machine Weight | 700 kg |
| Battery Capacity | 200 AH | Machine Dimensions (L x W x H) (mm) | 2400*2000*2000 |
| Dust Collection Filter Area | 10 m² | Package Dimensions (L x W x H) (mm) | 2650*2100*2100 |
|Key Highlights
Smart Side Brush System: Equipped with a multifunctional intelligent front lift arm, allowing independent adjustment of the side brushes' height and width to adapt to complex cleaning environments. Features an integrated smart anti-collision system to prevent damage during edge-cleaning operations.
High-Power Drive & Patented Suspension: Powered by a 2200W high-performance AC drive motor and a fully enclosed aluminum alloy transaxle, supporting ultra-quiet stepless speed control. Includes a patented balanced hydraulic damping system that automatically levels the machine on inclines, significantly enhancing operator comfort and mechanical stability.
Auxiliary Cleaning Tool (Optional): Equipped with a 58V lithium-powered high-velocity blower. This allows operators to clear leaves and debris from areas inaccessible to the machine (such as under parked cars or on narrow sidewalks) into the sweeper's path. It can also be used for air filter maintenance.
Advanced Dust Control & Sweeping:
Rear-Throw Technology: Counter-rotating brushes utilize inertia to throw waste directly into the hopper for maximum efficiency.
Triple-Nozzle Misting: Features three fan-shaped atomizing nozzles (33% more coverage than standard models) for superior dust suppression in heavy-duty environments.
Large-Scale Filtration: An 8㎡ imported Toray polyester filter paired with a 600W rare-earth permanent magnet fan ensures zero dust leakage.
|Functional Features
1. Maximum Storage & Endurance:
190L Large-Capacity Hopper: A detachable waste container that minimizes downtime by reducing the frequency of unloading.
Flexible Battery Configuration: Supports 100AH or optional 135AH high-capacity batteries, ensuring a full 6–8 hour shift capability.
2. Premium Control & Safety:
U.S. KELLY Controller: Paired with an 11-channel integrated PCB control panel for industry-leading system stability.
10-Point Overload Protection: Independent insurance for the main brush, side brushes, drive, and suction motors to protect core components from electrical damage.
3. Industrial Durability & Safety:
High-Pressure Disc Brakes: Professional-grade braking assembly for precise stopping power on slopes and under full loads.
Corrosion-Resistant Chassis: An innovative lightweight frame treated with anti-corrosion coating to prevent rust and deformation while extending runtime.
